Specifications of TIMKEN Bearing M268730H
Specifications
Series |
M268700 |
Cone Part Number |
M268730H |
Design Units |
Imperial |
Cage Type |
Stamped Steel |
C1 – Dynamic Radial Rating (Two-Row, 1 million revolutions)1 |
1100000 lbf4870000 N |
C90(2) – Dynamic Radial Rating (Two-Row, 90 million revolutions)2 |
284000 lbf1260000 N |
Abutment and Fillet Dimensions
R – Cone Backface “To Clear” Radius3 |
0.25 in6.4 mm |
da – Cone Frontface Backing Diameter |
16.34 in415 mm |
db – Cone Backface Backing Diameter |
16.73 in425 mm |
Ab – Cage-Cone Frontface Clearance |
0.31 in7.9 mm |
Aa – Cage-Cone Backface Clearance |
0.45 in11.4 mm |
a – Effective Center Location4 |
-0.37 in-9.4 mm |
