Specifications of TIMKEN Bearing L910349
Specifications
Cone Part Number |
L910349 |
Design Units |
Imperial |
Cage Type |
Stamped Steel |
C1 – Dynamic Radial Rating (Two-Row, 1 million revolutions)1 |
17100 lbf76300 N |
C90(2) – Dynamic Radial Rating (Two-Row, 90 million revolutions)2 |
4450 lbf19800 N |
Abutment and Fillet Dimensions
R – Cone Backface “To Clear” Radius3 |
0.040 in1.020 mm |
da – Cone Frontface Backing Diameter |
2.72 in69 mm |
db – Cone Backface Backing Diameter |
2.76 in70 mm |
Ab – Cage-Cone Frontface Clearance |
0.08 in2 mm |
Aa – Cage-Cone Backface Clearance |
0.05 in1.3 mm |
a – Effective Center Location4 |
0.45 in11.4 mm |
