Specifications of TIMKEN Bearing 941 - 932-B
Specifications
| Series |
935 |
| Cone Part Number |
941 |
| Cup Part Number |
932-B |
| Design Unit |
Inch |
| Bearing Weight |
25 lb11.3 Kg |
| Cage Material |
Stamped Steel |
Dimensions
| d – Bore |
4 in101.6 mm |
| D – Cup Outer Diameter |
8.3750 in212.725 mm |
| D1 – Flange Outer Diameter |
8.8085 in223.736 mm |
| B – Cone Width |
2.6250 in66.675 mm |
| C – Cup Width |
2.125 in53.975 mm |
| C1 – Cup Flange Width |
0.4375 in11.113 mm |
| T1 – Bearing Width to Flange |
0.9375 in23.813 mm |
Abutment and Fillet Dimensions
| R – Cone Backface “To Clear” Radius1 |
0.280 in7.100 mm |
| r – Cup Backface “To Clear” Radius2 |
0.130 in3.3 mm |
| da – Cone Frontface Backing Diameter |
4.61 in117 mm |
| db – Cone Backface Backing Diameter |
5.12 in130 mm |
| Da – Cup Frontface Backing Diameter |
7.87 in199.90 mm |
| Ab – Cage-Cone Frontface Clearance |
0.09 in2.3 mm |
| Aa – Cage-Cone Backface Clearance |
0.23 in5.8 mm |
| a – Effective Center Location3 |
-0.78 in-19.8 mm |
